A6370 Overspeed Protection Monitor The A6370 Monitor is part of the AMS 6300 SIS Overspeed protection system and is mounted in a 19” rack (84HP width and 3RU height) in combination with the A6371 system backplane. One AMS 6300 SIS consists of three Protection monitors (A6370) and one backplane (A6371). The system is designed for use with Eddy-Current sensors, Hall- Element sensors and Magnetic (VR) Sensors.
EMERSON A6370 is an overspeed protection monitor, which is a part of AMS 6300 SIS overspeed protection system. It is mainly used to monitor the rotating speed of rotating mechanical equipment (such as turbines, compressors, pumps, etc.). When the rotating speed exceeds the set value, it will trigger an alarm or emergency stop to prevent equipment damage or accidents.
The equipment supports various sensor types, including Hall sensor, magnetic (VR) sensor and eddy current sensor. It has high accuracy and reliability and is suitable for harsh industrial environment.
A6370 monitor has various communication interfaces, such as USB, RS485 and Profibus DP, which supports remote monitoring and data transmission.
The Metrix 5485C is a moving-coil velocity transducer, designed for continuous use in elevated temperatures up to 375°C. A zero friction coil suspension provides accurate, repeatable vibration measurements over a wide range of amplitude and frequency and is built to withstand the high-g environments and cross-axis vibrations typical of gas turbines. The coil bobbin is suspended by two non-twisting, circular spider springs that provide a clean frequency response. Purely viscous electromagnetic damping is employed to eliminate friction-prone air damping and improving detection of small vibration amplitudes at low frequencies.
The sensor is available in two configurations: with integral ar mored cable or removable armored cable via a 2-pin MIL-style threaded connector. The case is constructed of stainless steel and its robust internals are hermetically sealed to ensure durability in the most hostile environments. The product is approved for use in Zone 2 / Div 2 hazardous areas without use of intrinsic safety barriers. It is also approved for use in Zone 0/1 and Div. 1 areas with use of an appropriate intrinsic safety barrier.
• Analog performance delivers excellent resolution
• Approved for use in hazardous areas
• Available with integral or removable cable
APPLICATIONS
• Gas Turbines
• Furnace Fans
• Machines with continuous or intermittent surface temperatures above 120°C
Notes:
1. Intrinsically safe when installed with appropriate intrinsic safety barrier per Metrix drawing 7623.
2. Non-incendive when installed per Metrix drawing 8096.
3. Temperature Classification for the 5485C varies as a function of the ambient temperature. Essentially, the 5485C’s surface temperature will not rise more than 40°C above its ambient surroundings, up to its rated maximum operating temperature of 375°C. See table below
SAFETY INTEGRITY LEVEL
SIL is a method or measurement unit to determine the reliability of electrical, electronic and programmable systems. The purpose of the SIL certification is to measure safety system performance and the likelihood of failure. Achieving SIL certification, based on the IEC61508 Functional Safety Standard, signifies that the product has been thoroughly assessed and is a reliable electronic device ready to use across a wide range of industries. Metrix products have been thoroughly evaluated by an independent third party agency on the basis of IEC61508 Functional Safety standards to obtain SIL certification.
ABB BC810K02 CEX bus interconnection unit is a communication module used in industrial automation system to improve the availability and redundancy of CEX bus. Its main functions include dividing CEX bus into multiple physical segments, thus improving the reliability and data transmission efficiency of the system. In addition, BC810K02 supports redundant communication interfaces, allowing CPU modules to be replaced without interrupting CEX traffic, thus ensuring the continuous operation of the system during maintenance.
The product contains the following components:
2 BC810 interconnection units
2 TP857 substrates
Two TK851 interconnection cables
Two TB850 CEX bus terminators.
BC810K02 is suitable for a variety of industrial automation scenarios, such as wind power, hydropower and nuclear power. It is compatible with a variety of equipment and systems, and supports high-speed data transmission and reliable interface connection. Its technical parameters include: the size is 127.5 mm (depth) ×185 mm (height) ×59 mm (width), and the weight is 1.55 kg, which conforms to RoHS standard and is suitable for the classification of small equipment.
BC810K02 is a high-performance industrial communication module. Through its redundant design and flexible interface configuration, it provides efficient data transmission and reliability guarantee for industrial automation system.
DCS 600 Overload Capability To match a drive system as efficiently as possible with the driven machine’s load profile, the armature power converters DCS 600 can be dimensioned by me ans of the load cycle. Load cycles for driven machines have been defined in the IEC 146 or IEEE specifications. The currents for the DC I to DC IV types of load (see table 2.3/2) for the power converter modules are listed in the table below.
The overload capacity of DCS 600 is one of the important characteristics of ABB DCS 600 multi-drive system, and its design goal is to match the load demand of drive system and driven machine as efficiently as possible. according to
The armature power converter of DCS 600 can be sized according to the duty cycle, which has been defined in IEC 146 or IEEE specification.
Specifically, DCS 600 supports various load types (such as continuous load DC I Continuous), and can provide corresponding current output capacity according to different load cycles (such as DC I Continuous, DC I Continuous 10% load duration of 15 minutes, etc.).
The system also has overload tolerance, which can continuously output time exceeding the rated current or power under certain conditions, thus ensuring the reliability and stability of the system.
The design of DCS 600 conforms to many international standards (such as IEC 61805-1-2022), and is certified by CE, UL and C-Tick, which is suitable for long-term stable operation in industrial environment.
The Paddle Lifter of Lam Research (model 853-032776-001) is a key component used in semiconductor manufacturing equipment. Its main function is to accurately control the lifting action to realize the up-and-down movement of the heating paddle. This kind of elevator is widely used in Rainbow’s independent 4520i and 9600 platforms to ensure the high accuracy and reliability of operation.
As a leader in the field of after-sales semiconductor equipment support, Semigroup focuses on providing high-quality new parts and refurbished parts. All parts meet or exceed the specifications of the original equipment manufacturer (OEM), and cover a variety of semiconductor equipment components, including servo motors, elevator stepper components, temperature controllers and so on.
According to the evidence, Lam Research’s paddle elevator series also includes other models, such as 853-032776-001, 853-032776-002, etc. These models may be slightly different in function or configuration, but they all belong to the same product line.
The 853-032776-001 paddle elevator of Lam Research is an indispensable part in semiconductor manufacturing, and its accuracy and reliability make it a part of the industry standard.
1. Similar models under the same product line
(for Lam Research 4520i and 9600 platforms)
853-032776-002 (possibly different batch or improved version)
853-032776-003 (upgraded version or different configuration)
853-032776-004 (for specific process adjustment)
2. Other Lam Research paddle elevator models
(Different platforms or optimized versions of functions)
853-032775-001 (possibly previous generation or simplified version)
853-032777-001 (Enhanced or Heavy Load Version)
853-032778-001 (for high temperature or special environment)
3. Compatible or refurbished models provided by Semigroup.
(Substitutes that meet or exceed OEM specifications)
SG-PL-LAM001 (refurbished or optimized version)
SG-PL-LAM002 (enhanced durability or precision adjustment)
SG-PL-LAM003 (for specific service kit)
4. Other related Lam Research elevator components
(May contain components with similar functions)
853-032779-001 (Elevator Stepper Motor Assembly)
853-032780-001 (Ball Screw Drive Version)
853-032781-001 (model with integrated temperature control)
If more specific model matching or technical parameter comparison is needed, it is recommended to refer to the official manual of Lam Research or contact Semigroup (Semigroup) technical support to confirm compatibility.
MM4-4TX/SFP introduced by Hirschman Automation and Control Co., Ltd. is an industrial-grade Gigabit Ethernet media module, which is suitable for various industrial application scenarios. Its main features include: Port configuration: The equipment provides four ports, supporting 10/100/1000BASE-TX (twisted pair) and 1000BASE-SX/LX (optical fiber), and users can choose any combination as required. For example, an SFP module can replace a TX port, and up to four ports can be used at the same time. Network size: Supported cable lengths range from 0 to 100 meters (twisted pair), as well as 50/125 or 62.5/125 micron multimode fiber and 9/125 micron single mode fiber. These optical fiber modules need to be used with corresponding LC connectors. Power supply and power consumption: The device is powered by the power supply of the mouse switch backplane, with a power consumption of 2W, which is characterized by low energy consumption. Diagnosis and environment: The equipment is equipped with diagnostic indicator lights, including power status, link status, data transmission rate (1000Mbit/s), auto-negotiation and full-duplex mode. The working temperature range is 0℃ to 60℃, the storage and transportation temperature range is -25℃ to 70℃, and the relative humidity is 10% to 95% (non-condensing). Mechanical characteristics: the size of the equipment is 38mm x 134mm x 118mm, the weight is 180g, and the protection grade is IP20. It is suitable for installation on DIN guide rail and has good mechanical stability. EMC performance: The equipment conforms to FCC CFR47 Part 15 and EN 55022 standard, has anti-interference ability and is suitable for electromagnetic interference scenes in industrial environment. Certification and safety: The equipment meets the safety standard of industrial control equipment (cUL 508) and the certification of dangerous places (cUL 1604 level 2). MM4-4TX/SFP is a powerful, flexible and reliable industrial Ethernet media module, which is suitable for industrial network environments that need high reli
MM4-4TX/SFP introduced by Hirschman Automation and Control Co., Ltd. is an industrial-grade Gigabit Ethernet media module, which is suitable for various industrial application scenarios. Its main features include: Port configuration: The equipment provides four ports, supporting 10/100/1000BASE-TX (twisted pair) and 1000BASE-SX/LX (optical fiber), and users can choose any combination as required. For example, an SFP module can replace a TX port, and up to four ports can be used at the same time. Network size: Supported cable lengths range from 0 to 100 meters (twisted pair), as well as 50/125 or 62.5/125 micron multimode fiber and 9/125 micron single mode fiber. These optical fiber modules need to be used with corresponding LC connectors. Power supply and power consumption: The device is powered by the power supply of the mouse switch backplane, with a power consumption of 2W, which is characterized by low energy consumption. Diagnosis and environment: The equipment is equipped with diagnostic indicator lights, including power status, link status, data transmission rate (1000Mbit/s), auto-negotiation and full-duplex mode. The working temperature range is 0℃ to 60℃, the storage and transportation temperature range is -25℃ to 70℃, and the relative humidity is 10% to 95% (non-condensing). Mechanical characteristics: the size of the equipment is 38mm x 134mm x 118mm, the weight is 180g, and the protection grade is IP20. It is suitable for installation on DIN guide rail and has good mechanical stability. EMC performance: The equipment conforms to FCC CFR47 Part 15 and EN 55022 standard, has anti-interference ability and is suitable for electromagnetic interference scenes in industrial environment. Certification and safety: The equipment meets the safety standard of industrial control equipment (cUL 508) and the certification of dangerous places (cUL 1604 level 2). MM4-4TX/SFP is a powerful, flexible and reliable industrial Ethernet media module, which is suitable for industrial network environments that need high reli
Hirschmann)MM4-2TX/SFP/SFP media module is a high-performance device specially designed for industrial Ethernet, which is suitable for MICE switches MS4120 and MS30 series. The module is powered by backplane and supports dual-port SFP interface, which can meet various network application requirements.
The main features of this module include:
Compatibility: MM4-2TX/SFP module is specially designed for Hirschmann PowerMICE management switch, which supports seamless integration with MS4120 and MS30 series switches.
Power supply mode: the module obtains power from the backplane of the switch without additional power supply, which simplifies installation and maintenance.
Transmission rate: Support the transmission rate of 1000 Mbps, which is suitable for high-speed data transmission.
Modular design: This module adopts modular design, which is convenient for expansion or replacement in the existing network and improves the flexibility and reliability of the system.
Global transportation and warranty: products can be transported by international logistics companies such as DHL, UPS and FedEx, and provide worldwide warranty services.
MM4-2TX/SFP module also has the following advantages:
High reliability: It is suitable for complex network requirements in industrial environment to ensure the stability and efficiency of the network.
Easy installation: the module is easy to install, and users can quickly deploy and optimize network performance.
Flexible application: Suitable for scenarios that need to expand network ports or improve network performance, such as factory automation and data centers.
Hirschman MM4-2TX/SFP media module is a powerful and reliable industrial-grade network device, which is suitable for network environments that need high performance and reliability. Its modular design and global warranty service further enhance the user experience and the long-term stability of the equipment.
Hirschmann MM20-P9P9T1T1SAHH is a high-performance industrial Ethernet media converter, which is suitable for various industrial environments. This product combines the consistent high quality and reliability of Hirschman brand, and is widely used in factory automation, remote monitoring and data transmission.
As a media converter, MM20-P9P9T1T1SAHH supports multiple communication protocols and can realize seamless connection between optical fiber and copper cable, thus providing stable and reliable communication performance. This feature enables it to operate normally in harsh environment, such as factory workshop or outdoor environment. In addition, the equipment also has flexible interface configuration and redundant design, which is convenient for users to adjust and manage according to their needs.
As a leading enterprise in the field of automation communication, Hirschman’s products usually have high performance characteristics, which can support high-speed data transmission and low-delay communication and meet the needs of modern network communication. MM20-P9P9T1T1SAHH is no exception, and its design aims to provide efficient and reliable solutions for industrial automation.
Hirschmann MM20-P9P9T1T1SAHH is a powerful and adaptable industrial Ethernet media converter, which is suitable for industrial application scenarios requiring high reliability and high performance network connection.
Note: Read these instructions carefully, and familiarize yourself with the device before trying to install, operate, or maintain it. The following notes may appear throughout this documentation or on the device. These notes warn of potential hazards or call attention to information that clarifies or simplifies a procedure. Symbol explanation This is a general warning symbol. This symbol alerts you to potential personal injury hazards. Observe all safety notes that follow this symbol to avoid possible injury or death. If this symbol is displayed in addition to a safety instruction of the type “Danger” or “Warning”, it means that there is a danger of electric shock and failure to observe the instructions will inevitably result in injury. This symbol indicates the danger of hot surfaces on the device. In connection with safety instructions, non-observance of the instructions will inevitably result in injuries.
Safety instructions
UNCONTROLLED MACHINE ACTIONS To avoid uncontrolled machine actions caused by data loss, configure all the data transmission devices individually. Before you start any machine which is controlled via data transmission, be sure to complete the configuration of all data transmission devices. Failure to follow these instructions can result in death, serious injury, or equipment damage
Certified usage
Use the device solely for the application cases described in the Hirschmann product information, including this manual. Operate the device solely according to the technical specifications.
Supply voltage The devices are designed for operation with Safety Extra-low Voltage (SELV). Connect only SELV circuits with voltage restrictions according to IEC 60950-1 or ES1 according to IEC/EN 62368-1 to the supply voltage connections and to the signal contacts. The supply voltage is electrically isolated from the housing.
Use undamaged parts.
For power supply via DC voltage: All following prerequisites are fulfilled:
There are fuses suitable for DC voltage in the positive conductors of the supply lines, or the voltage sources are appropriately current limited. Regarding the properties of this fuse: See “General technical data” on page 67.
The negative conductors of the voltage inputs are on ground potential.
For power supply via AC voltage: All following prerequisites are fulfilled:
There are fuses in the supply lines, or the voltage sources are appropriately current-limited. Regarding the properties of this fuse: See “General technical data” on page 67.
The power sources are electrically isolated from the ground
Relevant for North America: The device may only be connected to a Class 2 supply voltage that fulfills the requirements of the National Electrical Code, Table 11(b). If the voltage is being supplied redundantly (two different voltage sources), the combined supply voltages must fulfill the requirements of the National Electrical Code, Table 11(b).
Relevant for North America: For use in Class 2 circuits. Only use copper wire/conductors of class 1, 75 °C (167 °F). Start connecting the electrical wires only if all the above safety requirements are fulfilled
Use in Hazardous Locations
Relevant for North America for modules certified for Hazardous Locations: This equipment is suitable for use in Class 1, Division 2, Groups A, B, C and D or Non-Hazardous (unclassified) locations only. Make sure that peripheral devices are suitable for the application environment. The wiring for the voltage supply and for the inputs and outputs (I/O) must adhere to the wiring regulations for Class 1, Division 2 [article 501(b) of the National Electrical Code (USA), NFPA 70] and to the applicable statutory regulations. Note: Observe the control drawing (document number 000160011DNR) on the following pages. Avertissement – Risque d’explosion – Ne pas débrancher tant que le circuit est sous tension à moins que l’emplacement soit connu pour ne contenir aucune concentration de gaz inflammable. Avertissement – Risque d’explosion – La substitution de tout composant peut rendre ce matériel incompatible pour une utilisation en classe I, division 2
