This model is an important hardware component in the Woodward MicroNet and NetCon digital control systems.

1. Product Description

The Woodward 5501-471 is an Analog I/O Module specifically designed for the MicroNet platform. The MicroNet system is commonly used for complex control of gas turbines, steam turbines, and large reciprocating engines. The 5501-471 module serves as the sensor interface of the system, responsible for collecting analog signals such as pressure, temperature, and flow, and converting the instructions from the controller into the required analog drive signals for actuators (such as fuel control valves). Its design emphasizes high sampling rate and industrial-grade stability.

2. Technical Data Sheet

Model: 5501-471

Series: MicroNet / NetCon 500

Channel Configuration: * Input: Usually includes multiple analog inputs, supporting 4–20 mA current loop or 0–5V/0–10V voltage signals.

Output: Includes an analog output channel, mainly used to drive the proportional actuator.

Resolution: 16-bit (16-bit) A/D and D/A conversion, providing extremely high control sensitivity.

Isolation performance: There is full electrical isolation between the channel and the system backplane, which can effectively resist common-mode interference in industrial environments.

Environmental indicators:

Operating temperature: -40 °C to +70 °C.

Three-proof treatment: Circuit boards are usually coated with a corrosion-resistant coating (Conformal Coating), which is suitable for high-humidity or salt-spray environments.

3. Related Models / Components

Model 5501-471 usually works in conjunction with the following MicroNet hardware:

5466-316 / 5466-1035: CPU main processing module.

5464-834: FTM (Field Terminal Module) – Field Terminal Module (Field Terminal Block)

5501-467 / 5501-470: Modules for analog quantity or power monitoring of the same series (usually selected based on the number of channels and signal types).

9907-014: High-density shielded cable for connecting the module to the terminal block.

4. Application Cases (Application Examples)

Gas Turbine Governing: Real-time collection of pressure and temperature feedback at each stage of the turbine, and precise control of fuel flow.

Steam turbine control: Used for extraction steam control or pressure regulation of the condensation system.

Compressor Control System (CCS): In the crucial anti-surge logic, it processes rapidly changing analog quantity feedback.

Automated power generation unit: Monitoring various analog parameters of the generator (such as voltage, frequency feedback regulation, etc.).

5. Product Advantages and Features

High reliability: Specifically designed for Mission-Critical applications, supporting both standalone and redundant configurations of MicroNet.

Hot-swappable support: In a dual-redundancy configuration, faulty modules can be replaced while the system is running, without causing downtime.

Powerful self-diagnosis: The module has real-time monitoring capabilities, which can identify sensor breakage, loop faults, and internal component failures, and promptly report errors to the main station.

High-density integration: Multiple input and output channels are integrated within a compact plug-in space, optimizing the layout of the control cabinet.

6. Other Models in the Series

The I/O family of Woodward MicroNet includes several derivative models:

5501-467: Analog board cards with different measurement ranges or channel definitions.

5464-643: Input module specifically designed for thermocouples.

5464-658: Four-channel speed sensor input module (MPU/Proximity).

5462-758: High-density Discrete Input ModuleAnalog I/O Module

This model is an important component of the Woodward MicroNet series control system and is typically used as a high-performance analog input/output module or signal conditioning board.

1. Product Description

The Woodward 5501-467 is a universal analog I/O module specifically designed for the MicroNet digital control system.

The MicroNet system is a highly representative and reliable control platform in the industrial field.

The 5501-467 module is responsible for connecting various sensors (such as pressure, temperature, and flow transmitters) and actuators (such as proportional fuel valves) at the site.

It has high-resolution data acquisition capabilities, which can convert the analog current or voltage signals from the site into digital signals that the controller can handle, and can output precise control instructions.

2. Technical Data Sheet

Model: 5501-467

Series: MicroNet / MicroNet Plus

Input Channels (Analog Inputs): Typically equipped with 8 input channels, capable of handling 4–20 mA, 0–5 V, or 0–10 Vdc signals.

Output Channels (Analog Outputs): Typically, there are 2 to 4 output channels, mainly used for 4-20 mA proportional control.

Resolution (Resolution): 16-bit (16-bit) A/D and D/A conversion, ensuring extremely high control accuracy.

Isolation Voltage: The module features robust electrical isolation between channels or between channels and ground, effectively preventing electromagnetic interference (EMI) in industrial environments.

Operating Temperature: -40 °C to +70 °C.

Physical structure: Standard MicroNet plug-in structure, with self-locking handle.

3. Related Models / Components

The 3501-467 module is typically used in conjunction with the following hardware:

5466-316 / 5466-1035: MicroNet CPU main processing unit.

5464-834: FTM (Field Terminal Module) – Field Terminal Module (Field Terminal Block), used for connecting external cables.

9907-014: Special high-density shielded connection cable.

5450-435: Redundant power supply module.

4. Application Cases (Application Examples)

Gas Turbine Fuel Control: Collects the inlet pressure signal of the turbine and precisely controls the opening degree of the fuel regulating valve.

Steam turbine protection and regulation: Monitor steam flow and cylinder temperature, drive electric actuators.

Reciprocating engine control: Used for speed regulation and load balancing of large industrial engines.

Compressor Automation: In the anti-surge system of centrifugal compressors, processing high-speed analog feedback from transmitters.

5. Product Advantages and Features

High integrity design: Specifically developed for Mission-Critical applications, with an extremely low failure rate.

Hot-swappable support: In a redundant system, faulty modules can be replaced without interrupting the control process.

Advanced self-diagnosis: The module is equipped with an internal monitoring circuit that can automatically detect input short circuit (Loop Fail) or output open circuit, and report errors to the CPU.

Environmental resistance: The PCB board is coated with conformal coating for three types of protection, making it suitable for harsh industrial environments such as high humidity and salt fog conditions.

High-speed sampling: Capable of capturing rapidly changing transient signals, meeting the requirements of high-performance speed control systems.

6. Other Models in the Series

The Woodward MicroNet I/O family also includes:

5501-468: Variants with different channel densities or specific current ranges.

5464-658: Four-channel speed sensor input module (MPU/Proximity).

5464-643: Thermocouple Input Module.

5501-470: Power monitoring or dedicated conditioning module.

5466-258

Woodward 5466-258 Simplex 48/24 Discrete Input/Output Module for Both MicroNet and Vertex-Pro Chassis.

This unit has 1 Red Fault LED and is UL/ATEX Listed. The 5466-258 unit is part of the Vertex-Pro system for MicroNet Digital Controllers.5466-258 Technical Specifications

Air Quality    Pollution Degree 2

Control Type    Vertex-Pro Motor-Driven Compressor

Installation Overvoltage Rating    Category II

Listings    IL, ATEX, CE(EMC), DNV, ABS, and LRS

Module Type    Simplex Discrete 48/24 I/O Module

Operating Temperature Range    0-55°C

Storage Temperature    -40 to +105 °F

Weight    48 lbs. (22 kg) when in Chassis

About the 5466-258

The 5466-258 module is a Simplex Discrete Input/Output unit. The unit was produced by Woodward as part of the MicroNet Digital Control series which can also be used with a Vertex-Pro Chassis.

The typical hardware used with this unit is the MicroNet Plus hardware. This module can be used in both Simplex and Redundant systems.

This module can be used in any chassis module, whether eight or fourteen slots. Please note the locations for this unit must be non-hazardous or within Class I, Division 2. Groups A, B, C, and D.

The 5466-258 module is a forty-eight/twenty-four discrete combo module, this indicates that there are forty-eight inputs and twenty-four outputs.

There are two configurations that the module can be used in. One of them will consist of two twenty-four/twelve discrete FTMs which will connect to this module through two high-density discrete/analog cables.

The discrete inputs on this module will be optically isolated and can be accessed through the twenty-four/twelve FTMs when in the second configuration.

On the front faceplate, there is only one LED which indicates the potential faults. There are also two connectors on the module.

5501-470 is the core component of the Woodward MicroNet series control system.

It is typically defined as a power monitoring module or a specific function I/O regulating board (in the MicroNet architecture, this series part number is often used for power conversion or signal conditioning).

1. Product Description

The Woodward 5501-470 is a highly reliable electronic module specifically designed for the MicroNet digital control platform.

The MicroNet system is widely used in the control of large gas turbines, steam turbines, and reciprocating engines.

The main function of this module is to provide precise power management or specific analog signal processing within the system’s chassis (Chassis). It uses industrial-grade components and is capable of handling high-frequency signals in extreme environments, ensuring the data integrity of the control bus (Bus).

2. Technical Data Sheet

Model: 5501-470

Series: MicroNet / NetCon

Input Voltage: Usually used in conjunction with the rack power supply (18–36 Vdc or higher, depending on the rack configuration)

Power Consumption: Approximately 10–15 W

Physical dimensions: Standard size of MicroNet plugin board

Channel isolation: Possesses a high level of electrical isolation (Galvanic Isolation), preventing ground loop interference

Operating Temperature: -40 °C to +70 °C

Humidity range: 5% to 95% (non-condensing)

3. Related Models

The model 5501-470 typically works in conjunction with the following MicroNet components:

5466-316 / 5466-1035: CPU main processing module.

5464-414: General Analog Input/Output Module.

5450-435: Power Supply Module.

8928-396: Magnetic pickup (MPU) speed sensor.

4. Application Cases

Energy and Power: Installed in the distributed control cabinets of gas turbine combined cycle power plants, it is responsible for handling the critical fuel regulation logic.

Petroleum and natural gas: Anti-surge control systems for large centrifugal compressors, ensuring stability during high-speed operation.

Ship propulsion: Integrated with the Woodward maritime certification system, it controls the main propellers of large bulk carriers or liquefied gas ships.

Industrial Turbine: Monitors the inlet steam pressure and rotational speed of the steam turbine, achieving precise regulation within milliseconds.

5. Product Advantages and Features (Product Advantages and Features)

Redundancy Compatibility: This module supports the redundant configuration of MicroNet. In the event of a failure of a single module, the backup module can immediately take over, eliminating the risk of a system shutdown.

Self-diagnostic capability: The module is equipped with a built-in monitoring circuit that can detect abnormal voltages or internal hardware errors in real time and send an alert to the system.

Resistant to harsh environments: All PCB boards have been treated with conformal coating, effectively protecting against salt fog, moisture and industrial dust.

High-precision processing: Utilizing high-resolution digital-to-analog converters ensures that the signal sent to the actuator has minimal fluctuations, thereby enhancing mechanical efficiency.

6. Other Models in the Series

Modules with similar functions in the Woodward MicroNet series include:

5501-471: This variant of the model usually features different voltage ranges or channel configurations.

5462-758: High-density discrete quantity input module.

5466-409: Hybrid Signal Processing Board.

5441-694: Ethernet communication interface module

WOODWARD 9907-1200 Industrial Control System, Lightweight & Durable Speed Controller, Part of 723 Series

Weight:6 lbs 8 oz

Dimensions:Not specified in provided data

Location:Closed Industrial Control Cabinet

Manufacturer:WOODWARD

Power Consumption:<= 15 W

Series:723 and 723PLUS Digital Control

Temperature Range:Up to 70°C / 158°F

9907-1200

The WOODWARD 9907-1200 is a high-performance digital control system specifically tailored for industrial environments.

With its robust design, it is capable of handling tough conditions, ensuring reliable operation in demanding applications.

Equipped with load-sharing line relays, high/low voltage protection, and reverse/forward acting functions, it provides versatile control options.

Its compact and lightweight form factor makes installation and maintenance a breeze, enhancing operational efficiency.

Compatible with a wide range of engines and turbines, this controller supports split shaft designs, offering seamless integration with existing systems.

Experience unmatched precision and reliability with the WOODWARD 9907-1200. designed to meet the stringent requirements of modern industrial control.

The Woodward 9907-1200 is a high-performance digital controller designed for industrial applications, providing advanced load sharing and speed control functionalities for efficient engine management in closed industrial environments

The same part number of Woodward sometimes has different names depending on the application field. 8446-1019 is primarily identified as the RP-3000 remote control panel (used for the easYgen series), and in some industrial channels, it is also classified as a digital speed controller component.

1. Product Description

The Woodward 8446-1019 is primarily used as the RP-3000 remote panel. It is a remote operation terminal specifically designed for the easYgen-3000 series generator set controllers. Through the CAN bus connection, this panel can fully mirror the operation interface of the main controller, enabling users to conduct real-time monitoring, parameter configuration, and start/stop operations from locations far away from the generator set (such as control rooms, bridge decks, etc.).

Core functions: Remote monitoring, parameter adjustment, alarm management, multilingual support.

Main components: High-resolution backlit display screen, sealed operation buttons, aluminum alloy industrial casing.

2. Technical Data Sheet

Model: 8446-1019 / RP-300

Supply Voltage: 12/24 Vdc (The range is usually 8–40 Vdc)

Communication Interface (Interface): CAN Bus (used for communication with the easYgen controller)

Insulation Voltage: A continuous 40 Vdc for a 1-second test can reach up to 100 Vdc.

Display screen: 4.2-inch multi-functional display with adaptive backlighting

Protection Level (Protection): The front panel reaches IP65 (when installed on the cabinet door), and the enclosure is IP20.

Operating Temperature: -20 °C to +70 °C

Weight: Approximately 1.5 – 2.0 kg

3. Related Models

This panel must be used in conjunction with Woodward’s main controller:

easYgen-3100/3200: Standard Generator Control System.

easYgen-3400/3500: Enhanced Generator Set Control System.

8446-1018: Another configuration version of the RP-3000 (P1).

8440-19xx series: Common part numbers of the main controller.

4. Application Cases (Hospital and Data Center)

8446-1019

Hospital and Data Center: Without entering the generator room, manage the status of the backup power system from the central control room.

Vessels and Offshore Platforms (Marine): The control panels will be installed on the bridge (Bridge), while the generator sets will be located in the engine room at the bottom.

Outdoor Switchgear: Operators can safely make grid connection and load distribution adjustments through this panel from within the room.

Mobile power station: Convenient for directly reading parameters and operating outside the vehicle-mounted control cabinet.

5. Product Advantages and Features (Product Advantages and Features)

Full Mirroring: It features an identical operation logic and display interface to the easYgen host, eliminating the need for relearning.

Multilingual support: Designed for global applications, it enables quick switching of display languages within the menu.

High security: Supports password protection function to prevent unauthorized personnel from modifying the core control parameters remotely.

Sturdy and durable: Equipped with an industrial-grade aluminum alloy casing and shock-resistant design, it meets the demanding requirements of harsh mechanical environments.

Integrated Diagnosis: It enables real-time viewing of various alarms, historical event records, and real-time waveform data of the generator set.

6. Other Models in the Series

The Woodward remote display and monitoring series includes:

RP-3000XT: A remote panel specially designed for the new generation of easYgen-3000XT series.

RP-1200: A compact and simple remote display unit.

easYgen-3200-P1/P2: The main controllers corresponding to different levels of function packages.
