Engine Generator Control Pack/Load Distribution (EGCP-3 LS)

The Woodward EGCP-3 LS controller is a microprocessor-based load controller designed to work with Woodward speed controllers and automatic voltage regulators for three-phase AC generators.

EGCP-3 LS is a synchronizer, a load controller, a dead bus closing system, a VAR/PF controller, a process controller, power and energy measurement and protection relays all integrated together.

The EGCP-3 LS is installed on a chassis in the front cabinet and has a keyboard and two 4-line display panels.

The display can be configured and set according to specific on-site requirements. The display can also be used for normal operation services to monitor operations and view alarm data.

All functions performed by the front panel and all parameters monitored can be obtained through three serial ports.

These ports can be configured to use Woodward Watch Window software, which is an external HMI and Modbus communication, or Servlink DDE software.

The 505 can be configured to use the EGCP-3 LS only as a synchronizer or as a synchronizer and load controller

. EGCP-3 LS provides phase matching or slip frequency, and is connected to the generator set’s automatic voltage regulator to match the voltage before parallel operation.

It is controlled by a speed bias signal with 505 to regulate the generator frequency and phase. position.

When configured to use only the EGCP-3 LS as the synchronizer, 505 must be configured to receive the EGCP-3 speed bias signal through the analog input, and this input can be enabled via contact input or function key.

When used as both a synchronizer and a load controller, the EGCP-3 LS performs automatic synchronization while the load is controlled according to the operation mode of the EGCP-3. The EGCP-3 LS can be set to basic load, load allocation, remote load settings, or process control mode, depending on the configuration and system conditions.

The load allocation mode of the EGCP-3 LS is used to distribute the load to any other units using the EGCP-3 LS and connected to the same isolation bus.

When paralleled to the grid, this mode is used together with the EGCP-3 MC to allow the EGCP-3 MC to control the power plant frequency or load, depending on its operating status.

The remote load setting mode of the EGCP-3 LS allows a remote 4-20 mA signal to set the load. EGCP

The process control mode of 3 LS allows control of any process directly related to the generator load.

After synchronization, the generator load can be controlled either by EGCP-3 LS (via 505 synchronous/load input) or by the internal speed/load setpoint of 505.

When the synchronous/load input is configured, the position of the grid breaker contacts is selected for the generator load control through EGCP-3 LS or the internal load setpoint of 505.

Once the generator is synchronized with the EGCP-3 LS software load, there are operation modes (base load, load distribution, process control) for the unit to the load setting.

When an instruction is received, EGCP-3 LS can also perform software de-synchronization of the unit, while issuing a breaker open command at a set power level.

The PowerSense board receives PT and CT inputs for the generator and bus for the calculation of parameters used by the system controller in EGCP-3.

The used algorithm is based on IEEE 1459-2000. The following parameters are provided for the generator and bus: Hz, Vac, Amps, W, VA, VAR, PF, phase, voltage offset, current offset, negative phase sequence voltage, negative phase sequence current.

An optional 4–20 mA analog output is available: synchronous oscilloscope, generator measurement, line measurement.

EGCP-3 LS has the following bus protection:

Overvoltage/Undervoltage (59. 27)

Overfrequency/Undervoltage (810. 81U)

Directional (Forward/Reverse) Power (32) *

Negative Sequence Overcurrent (46)

Negative Sequence Overvoltage (47)

Phase Overcurrent (51) *

Phase Limiting Overcurrent (51V) *

Directional VAR

Phase Voltage Unbalance (46) *

The EGCP-3 LS comes with the following generator protection:

Overvoltage/Undervoltage (59. 27)

Over-frequency/Under-frequency (81O, 81U)

Directional (input/output) power (32) *

Negative sequence overcurrent (46)

Negative sequence overvoltage (47)

Phase overcurrent (51) *

Directional VAR

Phase voltage imbalance (46) *

Speed/frequency mismatch

Apply 505 together with redundant I/H or I/P converters

505 can be applied in single or redundant actuator systems. For redundant actuator applications, the actuator

channel 1 is configured as the leader for HP instructions, and channel 2 is configured for zero-offset HP2 requirements. This

The selection of providing the full current to the driven equipment from the two actuator drive circuits can be accomplished using a diaphragm valve or a solenoid valve.

The converter state (I/H or I/P) and the pressure feedback signal can be selectively configured into 505. If necessary, the relay output can be configured to switch between the converter outputs.

The manual switching between converters can be initiated by discrete input, Modbus or PC interface commands.

The automatic switching between converters is provided by 505 based on the driver failure, converter state, converter output pressure and the servo mechanism input pressure feedback signal.

9907-149

9907-149 ProTech 203 Electronic Overspeed Trip Device from Woodward that senses prime mover speed through three magnetic pickups (MPUs).

9907-149 Technical Specifications

Dimensions    W19in x H12.244in x D5.62in

Features    Hot Replacement

Input Voltage    120 Vac/dc

Keypad/Display    1 display and keypad per module

Manual    85204

Model    De-energize-to-Trip

Operating Temperature    –13 to +140 °F

Standards    NEMA 4/4x, IP54

Weight    Less than 17 lbs

About the 9907-149

9907-149

ProTech model 9907-149 is a 120 Vac/dc device. There is a separate power supply for each of the three speed-sensing units in this system.

This is part of the modular design of this Woodward overspeed protection device that enables such features as hot replacement of an individual unit and testing of individual units without taking the prime mover offline.

9907-149

Speed-sensing units A, B, and C in model 9907-149 are identical. On top of having separate power supplies, the units also have separate operator interfaces and alarm systems.

The three units are configured for a two-out-of-three voting method.

Prior to this hardware vote, the three units act independently, monitoring prime mover speed with magnetic pickups (MPUs) and individually performing speed calculations.

The three units that makeup ProTech model 9907-149 must be programmed with identical trip points.

PROGRAM mode is accessed with a key switch that is connected to all three units. Due to the modular design of this Woodward system, units are programmed separately.

Tunable parameters are set when the units are in PROGRAM mode. These parameters are:

Trip Speed Set Point (250 rpm to 25.000 rpm)

MPU Gear Teeth (20 to 120)

MPU Failed Timeout (1 sec to 533 min 20 sec)

MPU Failed Set Point (100 rpm to 25.000 rpm)

Trip on MPU Failure

Timer Starts on Reset

Alarm If Speed Is < MPU Failed Set Point

These parameters, along with Present Speed, Peak Speed, Lamp Test, and Trip Cause, can all be viewed on the unit operator interface while the unit is in MONITOR mode.

Product Description

The Woodward 9907-165 is a 723PLUS high-performance digital speed controller (Digital Speed Control).

It is a fully digital control device based on a microprocessor, specifically designed for reciprocating engines (diesel, natural gas or dual fuel) as well as turbines.

This controller can provide precise speed control, load distribution, and serial communication capabilities with modern industrial automation systems, and is the core component of the prime mover control system.

2. Technical Data Sheet

Model: 9907-165

Input Power (Power Supply): High Voltage version, supporting 90–150 Vdc.

Speed Sensing Input: 2 magnetic pick-up devices (MPUs) or proximity switch inputs.

Analog Inputs: 4 channels (4–20 mA or 0–5 Vdc), used for load sensors, remote speed settings, etc.

Analog Output (Analog Outputs): 3 channels (4–20 mA), used to drive actuators or for remote display.

Discrete Input/Output (Discrete I/O): 8 channels of discrete input, 3 channels of relay output (discrete output).

Communication Port (Communication): 2 serial ports (RS-232. RS-422. RS-485), supporting Modbus protocol.

Operating Temperature: -40 °C to +70 °C.

Certifications: CSA certification, compliant with CE standards.

3. Related Models / Components

9907-018: Handheld Programmer, used for parameter settings.

9906-619 / 9906-700: The low-voltage version of 723PLUS (18–40 Vdc).

8200-226: ProAct actuator (often used in conjunction with 723PLUS).

Watch Window: A software tool used for debugging and monitoring on the PC side.

4. Application Cases (Application Examples)

Generator Load Sharing: This is used for the parallel operation of multiple engines to ensure a proportional balance of the load.

Marine Propulsion System: Controls the rotational speed and fuel limits of the main propulsion engine, and is capable of handling complex load variations.

Gas Compressor: Maintains the constant rotational speed of the reciprocating compressor.

Dual Fuel Engines: Precisely adjust the fuel ratio to ensure the engine’s efficiency in different fuel modes.

5. Product Advantages and Features (Product Advantages and Features)

Full digital precise control: Compared to analog systems, it eliminates zero drift and provides higher precision PID regulation.

Multiple communication protocols: The flexible serial communication enables seamless integration with distributed control systems (DCS) or PLCs.

Powerful filtering function: Built-in flexible torsional vibration filtering algorithm to protect the transmission system from mechanical stress damage.

Extremely adaptable to the environment: With a wide operating temperature range and a vibration-resistant design (installed in the cabinet), it is suitable for harsh industrial and marine environments.

Flexible configuration: Through the software configuration in the form of a logic block diagram, it can adapt to different control strategies (such as sag control, isochronous control, etc.).

6. Other Models in the Series

The Woodward 723PLUS series is divided into multiple sub-models based on the input voltage and specific functions:

9907-162: Low-pressure version 723PLUS.

9907-164: A version with special interlocking functions.

9905 Series (Legacy 723): The predecessor product of 723PLUS (the older 723 digital control).

DSLC-2: Woodward’s digital synchronization and load controller for power station management, often used in conjunction with 723PLUS to achieve automatic grid connection

WOODWARD 9907-167 Digital Governor
The Woodward 9907-167 Digital Governor is an advanced industrial control system designed for precise speed and load regulation in heavy-duty applications, ensuring optimal performance and reliability across various sectors.
Dimensions (LxHxD):14 inches x 11 inches x 4 inches

Enclosure Type:NEMA 4 rated

Program Upload/Download Capability:Yes

Input Voltage:18-32 VDC

Keypad/Display:30 Analog Keys with 2 Rows of 12 Characters

Manufacturer:Woodward

Operating Temperature Range:-13°C to +149°F

Output Type:2 Actuator Outputs, 8 Relay Outputs, 6 Programmable Current Outputs

Resolution:High

Standards Compliance:Meets US MIL-STD-810C, method 516.2- 1, procedure 1B

Weight Before Shipping:<10 lbs.

9907-167

Engineered for durability and precision, the Woodward 9907-167 Digital Governor integrates advanced technology to optimize the operational capabilities of industrial machinery. Its compact design ensures seamless integration into existing systems without compromising on functionality.

9907-167

With a comprehensive suite of features, including program upload/download capability and a robust input voltage range of 18–32 Vdc, this governor ensures flexibility and reliability across different industrial environments. The inclusion of 30 Analog Keys on its keypad offers intuitive control, making it accessible to a wide range of users.

Designed to withstand harsh conditions, the unit is equipped with shock protection standards meeting US MIL-STD-810C, ensuring longevity and reliability even under extreme circumstances. This makes it ideal for use in industries where equipment must operate reliably in challenging environments.

The programmable outputs allow for customized control over actuators and relays, providing users with the ability to tailor the system to meet specific operational needs. The 6 Programmable Current Outputs further enhance its versatility, supporting a variety of applications within the industrial sector.

Weighing less than 10lbs before shipping, the Woodward 9907-167 Digital Governor is lightweight yet robust, facilitating easy installation and maintenance. Its compact size and efficient design make it an attractive choice for space-constrained industrial settings, aiming to streamline operations and reduce costs

MicroNet HD Combo Modules

5466‐253 and 5466‐316

The subject modules provide a combination of eight Analog Inputs, four Analog Outputs, four Speed Inputs,

and two Proportional Actuator Outputs. These older modules have significant component obsolescence

issues and will be replaced by improved Combo Modules based on Woodward’s modern “Smart-Plus”

architecture.

The new modules provide four analog outputs (which can be used to drive 4-20mA proportional actuators),

twelve analog inputs and four speed inputs.  The new modules provide many performance improvements:

 Enhanced speed sensing, including improved resolution, throughput time, noise filtering and

channel to channel isolation. There are two versions available – standard speed accuracy

(meets/exceeds HDCombo accuracy), and high speed accuracy, which is primarily intended for

Gas Turbine applications but can be used for Steam as well when higher accuracy is desired.

 Acceleration sensing improvements – improved resolution, accuracy and noise filtering.

 Analog input channel improvements – improved resolution, accuracy, throughput time, channel to

channel and channel to ground isolation.

 Actuator/analog output improvements –improved resolution, accuracy, open wire detection,

isolation and noise filtering.

The new HD Combo modules have GAP-selectable Speed and Analog Input types, so either the standard

or high-accuracy version can be used in both MicroNet Plus(1) and 5200-based TMR(2) systems. See the

table below for FTM application.

5466‐253

Notes:

1. MicroNet Plus systems utilizing the new module will require Coder MicroNet 1.0 or later.

2. MicroNet TMR systems utilizing the new module will require Coder Version 5.08 or later.

3. Customers with 040 or Pentium/NT CPUs should continue to utilize 5466-253 and 5466-316 for

spare parts and system expansions.

Affected Units

Existing

P/N

5466‐253

Description Existing FTM Replaced By New FTM

5466-253 TMR High Density Combo I/O – 4 MPU’s,

(8) 0-5 Volt Inputs, 4 4-20 mA Outputs, 2

Prop. Actuator Outputs

2 x 5501-365 5466-1115 (Standard Accuracy)

or

5466-1105 (High Accuracy)

1 x 5501-372

1 x 5501-502

5466-316 Simplex High Density Combo I/O – 4

MPU’s, 8 4-20 mA Inputs, 4 4-20 mA

Outputs, 2 Prop. Actuator Outputs

5501-371 5466-1115 (Standard Accuracy)

or

5466-1105 (High Accuracy)

1 x 5437-523

1 x 5501-376

Corrective Action

The replacement modules require GAP updates as noted above and utilize different FTMs and cables. For

this reason, the old modules will continue to be available for users needing spare parts and or system

expansion.

Because the existing HD Combo modules and matching FTMs will remain available, Woodward is not

offering last time buy opportunities.

Customer Action

Please switch new system orders to the updated HD Combo module as soon as reasonably possible.

This helps Woodward preserve obsolete part inventory so that we can continue to offer the 5466-253

and 5466-316 modules as long as possible for spare parts or to expand existing systems.

Load Sharing Module

0.5–4.5 Vdc Output

9907-252

The Woodward Load Sharing Module is made for use with engines equipped with speed controls that

accept a 0–5 Vdc speed setting. The Load Sharing Module allows use of Woodward power generation

accessories and allows load sharing between engines equipped with speed controls that are not

manufactured by Woodward and engines controlled with Woodward electronic controls, or controls using

other Woodward load sharing modules.

Description

The Load Sharing Module provides isochronous and droop load-sharing capability for engines in

generator set applications. Additional equipment in the control system can include the Woodward SPM-A

Synchronizer, Import/Export Control, Automatic Generator Loading Control, and Automatic Power

Transfer and Loading Control.

Introduction

This section contains general installation instructions for the Load Sharing Module. Environmental

precautions and location considerations are included to determine the best location for the Load Sharing

Module. Additional information includes unpacking instructions, electrical connections, and an installation

check-out procedure.

Unpacking

Before handling the Load Sharing Module, read page ii, Electrostatic Discharge Awareness. Be careful

when unpacking the Load Sharing Module. Check the unit for signs of damage such as bent or dented

panels, scratches, and loose or broken parts. Notify the shipper of any damage.

Location Considerations

Consider these requirements when selecting the mounting location:

• Adequate ventilation for cooling

• Space for servicing and repair

• Protection from direct exposure to water or to a condensation-prone environment

• Protection from high-voltage or high-current devices, or devices which produce

electromagnetic interference

• Protection from excessive vibration

• An ambient operating temperature range of –40 to +70 °C (–40 to +158 °F)

Do not mount the Load Sharing Module on the engine.

Figure 1-2 is an outline drawing of the Load Sharing Module. Install the unit as close as practical to the

electronic engine control, but not on the engine itself. It may be installed in any position.

To maintain compliance with CE and UKCA marking requirements, the European Union Low Voltage

Directive requires that the Load Sharing Module (LSM) be mounted in an IP43 enclosure as defined in

EN60529. Access to the Load Sharing Module must be restricted to qualified personnel.

General Wiring Requirements

The circled ground symbol identifies the Protective Earth Terminal. This terminal must be

connected directly to protective earth using a grounding conductor at least as large as those

used on terminals 1 through 9. The insulation of the grounding conductor must be of green and

yellow color.

This symbol identifies functional or EMC earth. This terminal is to be used for cable shield

connections only. It is not to be used as a protective earth terminal.

External wiring connections and shielding requirements for a typical installation are shown in the plant

wiring diagram, Figure 1-4. These wiring connections and shielding requirements are explained in more

detail in this chapter.

9907-252

To maintain compliance with CE and UKCA marking requirements, the Low Voltage Directive requires

that the Load Sharing Module must only be connected to Class III equipment.

Wiring for the Load Sharing Module must be suitable for at least 90 °C (194 °F) and also be suitable for

the maximum installed operating temperature.

The Load Sharing Module must be permanently connected and employ fuses or circuit breakers in each

of the PT lines to limit current to the LSM PT inputs to no more than 5 A. In addition, a 2 A fast-acting fuse

or circuit breaker must be provided in the 24 Vdc power supply line.

All terminal block screws must be tightened to 0.56 to 0.79 N·m (5.0 to 7.0 lb-in).

To maintain compliance with CE and UKCA marking requirements, the EMC Directive requires that all

shields be connected to the terminals provided per the plant wiring diagram, Figure 1-4.

Power Requirements

9907-252

The Load Sharing Module is powered from a 24 Vdc source. The 24 Vdc source must be a minimum of

18 Vdc and a maximum of 32 Vdc continuous. If a battery is used for operating power, an alternator or

other battery charging device is necessary to maintain a stable supply voltage.

Shielded Wiring

All shielded cable must be twisted conductors with either a foil or braided shield. Do not attempt to tin (put

solder on) the braided shield. All signal lines should be shielded to prevent picking up stray signals from

adjacent equipment. Connect the shields to the terminals indicated in the plant wiring diagram. Wire

exposed beyond the shield must be as short as possible.

The other end of the shields must be left open and insulated from any other conductor. Do not run

shielded signal wires with other wires carrying large currents. See Application Note 50532. EMI Control

for Electronic Governing Systems, for more information.

Where shielded cable is required, cut the cable to the desired length and prepare the cable as instructed

below and shown in Figure 2-1.

Introduction

This chapter describes the operation of the Load Sharing Module and its internal circuits. Figure 1-3 is a

block diagram of the circuits in the module.

The Load Sharing Module senses the power output of a generator and provides a 0.5–4.5 Vdc signal to

the speed control to adjust the power output of the engine-generator set to match the reference power

level. The Load Sharing Module can also produce a droop condition (instead of isochronous load

sharing), making it possible to connect the generator set in parallel with either a generator set which is

running isochronously, or with an infinite bus.

Power Supply

The internal power supply generates a regulated dc voltage for the operation of the circuits in the Load

Sharing Module. The power supply gets its power from the engine 24 Vdc power source. To prevent

damage to the unit that uses an alternator or battery charging device, make sure the charging device is

turned off before disconnecting or connecting the 24 Vdc supply to the unit.

Power Sensor

Generator load is measured by the power-sensor circuit of the Load Sharing Module. The power-sensor

circuit senses current amplitude and produces a load signal proportional to the current amplitude times

the power factor. The potential input comes from potential transformers (PTs) and the current input comes

from the current transformers (CTs). The circuit uses these two inputs to generate a load signal which is

then filtered and sent to the controller circuit. The load signal voltage of each generator set will be

proportional to the percentage of rated load on the generator set.

Ammeters and voltmeters may be driven with the same PT and CT wires.

Load Comparator Circuit

In the load comparator circuit, the load signal voltage is balanced with the other generator sets in the system via

the load sharing lines. The comparator circuit of each Load Sharing Module includes a load gain potentiometer to

adjust each generator set’s load signal so that the load signal voltage of each is the same at full load. This

compensates for varying CT ratios or different generator set sizes. The load sharing voltage will be one-half the

measured voltage of the load signal test point.

Speed Trim Circuit

A speed-trim potentiometer can be added to the Load Sharing Module to permit remote adjustment of the

load or frequency of the generator. The speed trim is normally used for manual synchronization of a

generator set with an existing bus or to change the load demand when in droop mode.

Isochronous Load Sharing

Each comparator circuit compares the load signal voltage for its generator set to two times the voltage on

the load sharing lines and produces an error voltage proportional to the difference. This error voltage is

used to generate a pulse width modulated signal which is output to the speed control. This output biases

the speed loop of the speed control until the load signal voltage is equal to that of other generators on the

load sharing lines.

Droop Operation

In droop operation, a portion of the load signal voltage is fed to the controller circuit. This voltage is used

by the comparator circuit to reduce the control output by a percentage determined by the DROOP

potentiometer. The output is reduced, and the speed control reduces engine power output according to

the desired droop percentage.

When a generator set using the Load Sharing Module is paralleled in droop with other generator sets, the

common load signal on the paralleling lines is not used. The frequency of the generator set will therefore

vary with load, so it must be determined by a different means. In an isolated system with two or more

generator sets paralleled, if isochronous speed control is required, one of the generator sets must be

running in the isochronous (constant speed) mode. This generator set maintains the frequency of the

system. If a generator set is in droop and is paralleled with an infinite bus, the bus determines and

maintains the frequency. The DROOP percentage and the speed setting on the engine speed control

determine the amount of the load that is carried by the generator, when running in droop.

Auxiliary Equipment

The Woodward SPM-A synchronizer functions by biasing the output of the Load Sharing Module. All other

Woodward auxiliary generating control equipment functions by biasing the voltage on the load-sharing

lines.

0.5–4.5 Vdc Output

The Load Sharing Module output to the engine control is a 0.5 to 4.5 Vdc signal. The output nominally is

at 2.5 Vdc when the difference between the generator load and the signal on the load sharing lines is

zero.

The speed control should be set up in Variable Speed Governor mode to produce a ±10% variance in the

engine speed with a ±2.0 Vdc input, as shown in this example:

If 1800 rpm is equivalent to 60 Hz for a ±5.0% variance on the speed of the engine, the control would be

set up such that 0.5 Vdc output corresponds to 1710 rpm (VSG MIN

9907-164

Woodward Unit 9907-164 from 505 Digital microprocessor-based Controllers for Steam Turbines with Single or Split-Range Actuators.

9907-164 Technical Specifications

Model Number    9907-164

Dimensions    14W x 11H x 4D (Inches)

Display Type    Two line x 24 characters

Enclosure Type    IEC 60529. IP 56

Features    Overspeed Test Buttons

Humidity Standards    20 and 55 °C at 95% for 48hrs

Input Voltage    +24 Vdc at 1 A

Keypad/Display    30 Multi-function Keypad

Operating Temperature    –4 to +140 F

Slot Type    RS-232/RS-422 with Modbus Protocol

Software Version    505View or OpView™

Storage Temperature    -40 to +185 F

Weight    9.11 lbs

9907-164

Shipping Dimensions    20x16x16 inAbout the 9907-164

The device listed here is the 9907-164 model, a part of the 505 and 505E Microprocessor-based governor control units. These control modules were designed specifically to operate steam turbines, as well as turbogenerators and turboexpander modules. The 505/505E series was developed, produced, and manufactured originally by Woodward Inc. Woodward is the oldest industrial manufacturer in America, founded in 1870. and still, today remains one of the leading industrial companies in the market.

9907-164

The 9907-164 unit is designed to control the steam turbine by operating a single extraction and/or the admission for the turbine. It utilizes the turbine’s split-stage actuators, either one or both of them, to drive the inlet valves for steam.

This unit, like any of the 505 governor modules, is able to be configured in the field by the on-site operators. The menu-driven software is controlled and altered by the operator control panel integrated onto the front-facing side of the unit. The panel has a display of two lines of text, 24 characters per line.

The 9907-164 is outfitted with a series of discrete and analog inputs: 16 contact inputs (4 of them dedicated, 12 of them programmable), and then 6 programmable current inputs, at 4 to 20 mA. The standard features included into the 9907-164’s capabilities are the critical speed avoidance, valve limiters, the auto start sequence, and the first-out indicator for shutdowns.

This model is a very crucial general-purpose analog input/output module in the Woodward MicroNet and NetCon control systems.

1. Product Description

The Woodward 5464-414 is a standard analog I/O module. It is specifically designed for the MicroNet digital control system and is used for monitoring and controlling prime movers (such as gas turbines, steam turbines, and large engines).

This module, through its high-density channel design, can simultaneously handle multiple analog signals and serves as the core interface between the system and on-site sensors and actuators.

2. Technical Data Sheet

Model: 5464-414

Series: MicroNet / NetCon 500

Input Channels (Inputs): * Usually consist of 8 analog inputs.

Supports 4–20 mA current signal or 0–5 V / 0–10 V voltage signal.

Output Channels (Outputs): * Usually consists of 4 analog outputs.

Mainly used for 4-20 mA proportional control.

Accuracy: 0.1% of full scale (typical value).

Isolation: The module has current isolation between the channel and the bus, preventing external electromagnetic interference (EMI) from affecting the control system motherboard.

Operating Temperature: -40 °C to +70 °C.

Power Consumption: Approximately 5 – 10 W.

5464-414

3. Related Models / Components

The model 3464-414 is usually used in conjunction with the following Woodward hardware:

5466-316 / 5466-1035: MicroNet CPU main processing module.

5464-834: Analog Input Terminal Block (FTM – Field Terminal Module).

9907-014: Special shielded cable for connecting the module to the terminal block.

5464-544: Discrete (Discrete) I/O module.

5464-414

4. Application Cases (Application Examples)

Gas Turbine Control: This is used to collect exhaust temperature and fuel pressure signals, and to output signals to control the fuel regulating valve.

Steam Turbine Governing: Monitors the rotational speed of the steam turbine (in conjunction with the speed module) and the inlet steam pressure, and drives the servo actuator.

Compressor Anti-Surge Control: Real-time collection of pressure and flow transmitter data to ensure the compressor operates within a safe range.

Grid connection of the generator set: Processing power measurement signals and voltage regulation instructions.

5. Product Advantages and Features

High Reliability: Specifically designed for industrial mission-critical applications, with an extremely long Mean Time Between Failures (MTBF).

High-density design: Integrating input and output functions within a single slot, saving space in the control cabinet.

Hot-swappable support: In a redundant system configuration, it is supported to replace modules while the system is powered on without affecting its operation.

Powerful self-diagnosis function: The module can automatically detect loop breakage, short circuit or hardware faults, and report the error code to the main controller.

Resistant to environmental interference: Conformal coating can operate stably in high humidity and high salt spray environments.

6. Other Models in the Series

The Woodward MicroNet I/O series also includes:

5464-211: Special RTD (Resistance Temperature Detector) input module.

5464-643: Specialized thermocouple input module.

5464-658: High-speed counter/velocity sensor module.

5466-409: Discrete I/O Combination Module.
