5501-465

Woodward MicroNet Simplex Power Supply Board 5501-465 operates on an input voltage of 24 VDC,

the board will have a holdup time of five milliseconds. When redundant power supplies are used the 5501-465 board will occupy three slots

5501-465 Technical Specifications

Nominal Voltage Range    20 to 32 VDC

Storage Temperature    –40 to +105 °C

Standards    CSA, CE (LVD), CE (EMC), ABS, DNV, LRS

Operating Range    18 to 36 VDC

Chassis    MicroNet Simplex

Max. Power    531 W

Max. Current    2.95 A

Input Power Fuse/Breaker Rating    50 A Time Delay

About the 5501-465

5501-465

Model 5501-465 is another power supply board, but is specifically designed as a MicroNet Simplex model for the digital control series.

There are specific time delays and wire sizes required when operating the board at a specific input voltage range.

The input voltage range for this board is eighteen to thirty-two volts of direct current, the maximum fuse/c.b rating or the time delay will be fifty amperes; the wire size needed is ten millimeters squared or eight American wire gauge.

Please advise that the wires used must be rated for a minimum of one-hundred sixty-seven degrees Fahrenheit for use at an ambient temperature of ninety-five degrees Fahrenheit.

The 5501-465 board has four LEDs which are, an OK, a power supply fault, an input fault, and an overtemperature LED.

There are some troubleshooting checks that can be performed, one potential error that can occur is the voltages are not correct;

to ensure that the voltages are correct be sure that the provided power supply is in the correct range.

SPM-D10 Series

One Breaker Synchronizer

APPLICATIONS

SPM-D10 Series

One Breaker Synchronizer

DESCRIPTION

The SPM-D10 is a microprocessor-based synchronizer

designed for use on three phase AC generators equipped

with Woodward or other compatible speed controls and

automatic voltage regulators. The SPM-D10 synchronizer

provides automatic frequency, phase and voltage matching

using either analog- or discrete output bias signals.

The HJV Package provides additional mains protection.

Part-No. 8440-1668 SPM-D1040B/XN is a direct

replacement of the SPM-A synchronizer.

DESCRIPTION

Synchronizing

• Phase match or slip frequency synchronization with

voltage matching

Protection ANSI

HJV Packages

• Three-phase sensing of mains voltage

• Mains over-/undervoltage

• Mains over-/underfrequency

• Mains phase/vector shift

Control outputs

Standard

• Discrete raise/lower for speed

• Discrete raise/lower for voltage

X & XN Packages

(59/27)

(81O/U)

(78)

• Analog bias outputs for voltage and speed

freely configurable for all levels (+/-1 V,  +/

3 V, 0 to 5 V, 0.5 to 4.5 V, +/-10 V +/-5 V, 0

to 20 mA, +/-20 mA, and much more

configurable)

5448-890 SPM-D10

• Two-phase sensing of generator and bus

• Selectable operating modes like SPM-A (Run, Check,

Permissive, and OFF)

• Synchro-check possible

• Synchronization time monitoring

Isolated operation

• Frequency control

• Voltage control

Dead bus operation

• Closing of CB on demand

• Speed bias output configurable as 500 Hz

PWM output with  adjustable voltage level

• Two raise/lower outputs configurable for either

speed or voltage

Operating Features

• Two-line Liquid Crystal display for operation

and alarm indication

• Synchroscope

• Indication of control activity and breaker state

• Multi-level password protection for parameters

• Configuration directly or via PC

• English or German language adjustable

FURTHER SPM-D SYNCHRONIZERS

• The SPM-D10/YB Series provides three-phase generator and bus measurement

refer to product specifications 37298 for more information

• The SPM-D11 Series provides load/var sharing

refer to product specifications 37292 for more information

• The SPM-D21 Series provides synchronizing for two circuit breakers and load control

refer to product specifications 37293 for more information

SPECIFICATIONS (for more see specific manuals)

5448-890 SPM-D10

Accuracy………………………………………………………………………………Class 1

Power supply……………………………………………[Standard] 24 Vdc (+/-25 %)

[N & XN Packages] 90 to 250 Vac/dc

Intrinsic consumption…………………………………………………………max. 10 W

Ambient temperature……………………………………………………….-20 to 70 °C

[N & XN Packages] -20 to 60 °C

Ambient humidity………………………………………………95 %, non-condensing

Voltage………………..Rated /Δ: [1] 66/115 Vac or [4] 230/400 Vac

Maximum value (Vmax): [1] 150 Vac or [4] 300 Vac

Rated voltage Vph-ground: [1] 150 Vac or [4] 300 Vac

Rated surge voltage: [1] 2.5 kV or [4] 4.0 kV

Measuring frequency………………………………………………………..40 to 70 Hz

Linear measuring range up to……………………………………………….1.3×Vrated

Input resistance………………………………………….[1] 0.21 MΩ, [4] 0.696 MΩ

Max. power consumption per path…………………………………………< 0.15 W

Discrete inputs…………………………………………………………………… isolated

Input range…………………………………………………………..max. 250 Vac or dc

Input resistance……………………………………………………………approx. 68 kΩ

Relay outputs…………………………………………………………………….. isolated

Contact material…………………………………………………………………….AgCdO

Load (GP)…………………………………………………………….2.00 Aac@250 Vac

2.00 Adc@24 Vdc / 0.36 Adc@125 Vdc / 0.18 Adc@250 Vdc

Pilot duty (PD)………………………………………………………………………………….

1.00 Adc@24 Vdc / 0.22 Adc@125 Vdc / 0.10 Adc@250 Vdc

Housing………………………………………………Type APRANORM DIN 43 700

Dimensions……………………………………………………………..144×72×122 mm

Front cutout……………………………………………………138[+1.0]×67[+0.7] mm

Connection…………………………………………screw/plug terminals depending

on connector 1.5 mm² or 2.5 mm²

Front………………………………………………………………………insulating surface

Protection system…………………………………………..with correct installation

Front………………………………..

The Woodward 5437-1067A is a high-reliability individual module for the ProTech-GII series.

It is a critical component of Woodward’s Safety Integrity Level 3 (SIL-3) overspeed protection system, specifically designed to monitor and protect steam, gas, and hydro turbines from catastrophic overspeed or over-acceleration events.

Technical Parameter Table

Parameter	Specification
Model Number	5437-1067A
Series	ProTech-GII
Device Type	Individual Safety Module (for TMR architectures)
Voltage Input	High Voltage/Low Voltage (HV/LV) Voted
Response Time	8 to 26 milliseconds (Total system response)
Speed Input Type	Active or Passive Magnetic Pickups (MPU) / Proximity
Speed Range	0.5 to 32,000 RPM
Enclosure Rating	IP56 (Dust and Water Protected)
Communications	Modbus RS-485 / PCT Service Tool Interface
Safety Certification	IEC 61508 SIL-3 Certified

Related Models

The 5437-1067A is typically part of a triple-modular redundant (TMR) system:

8237-1246 / 8237-1369: The main bulkhead or panel-mount assemblies this module fits into.

5437-1078 / 5437-1119: Alternate spare modules with different relay or voltage configurations.

9927-1180: ProTech-GII Service Tool (software for configuration).

Application Cases

Nuclear & Fossil Power Plants: Used as the primary safety barrier for large-scale steam turbines to prevent runaway scenarios.

Mechanical Drive Turbines: Protecting turbines that drive compressors in oil refineries and gas processing plants.

Hydroelectric Dams: Managing the synchronization and emergency shutdown of water turbines.

Marine Propulsion: Installed on naval and commercial vessels to ensure engine safety in high-vibration maritime environments.

5437-1067A

Product Advantages and Features

Triple Modular Redundancy (TMR): Operates in a 2-out-of-3 (2oo3) voting logic. This ensures that a single module failure will not cause a nuisance trip or a failure to trip.

On-Line Repair: The modular design allows a single module (like the 5437-1067A) to be replaced while the turbine is running, significantly reducing plant downtime.

Acceleration Protection: Unlike basic overspeed trips, it calculates the rate of speed change (acceleration) to predict and prevent overspeed before it happens.

Integrated Logging: Maintains internal logs for the last 50 trips/alarms and 20 overspeed events with high-resolution timestamps.

Ruggedized Construction: Features sulfur-resistant conformal coating, making it suitable for Class 3C2 corrosive environments.

5437-1067A

Other Models in the Same Series

The ProTech-GII family is distinguished by its mounting and output types:

Bulkhead Mount Series: Designed for wall or skid mounting (e.g., 8237-1246).

Panel Mount Series: Designed for flush-mounting within a control cabinet (e.g., 8237-1600).

Voted Relay vs. Independent Relay: Depending on the model, the relays are either pre-voted internally or output independently to an external safety PLC.

English Introduction

The Woodward 5437-1067A is a specialized module for the ProTech-GII overspeed safety system.

It serves as a high-precision, microprocessor-based monitor that interfaces directly with magnetic speed sensors.

By utilizing 2-out-of-3 voting, the 5437-1067A provides the highest level of system availability and reliability, meeting global SIL-3 safety standards.

Its ability to be “hot-swapped” during operation and its advanced diagnostics make it a gold standard for protecting multi-million dollar rotating assets in the energy and processing industries

The Woodward 8440-1706 (SPM-D11) is a high-precision digital synchronizer designed for three-phase AC generators.

Part of the well-known SPM-D series, this “Synchronizer and Power Manager” is specifically engineered to automate the process of bringing a generator online by matching its frequency, voltage, and phase angle to a busbar or another power source.1

Technical Parameter Table

Parameter	Specification
Model Number	8440-1706 (SPM-D11)
Measuring Voltage	100/120 VAC or 400 VAC (Configurable)
Operating Frequency	50/60 Hz (Nominal)
Power Supply	18–32 VDC
Phase Angle Range	Adjustable ±1° to ±30°
Frequency Window	±0.05 Hz to ±0.5 Hz
Relay Outputs	Frequency/Voltage bias (+/-) and CB Close command
Interface	Two-line liquid crystal display (LCD)
Protection Rating	Front Panel IP54
Operating Temp	-20°C to +70°C

Related Models

The SPM-D11 is often paired with or replaced by these related components:

8440-1705 (SPM-D10): A similar synchronizer but typically used for single-phase sensing or simplified applications.

easYgen-3000 Series: More advanced power management controllers that incorporate the synchronizing functions of the SPM-D11.2

8440-1002 (SPM-D10/YB): A variant with specialized voltage/frequency bias characteristics.

LS-5 Series: Circuit breaker controllers often used in conjunction with synchronizers for complex busbar management.

Application Cases

Standby Generator Sets: Automatically synchronizing a backup generator to a building’s busbar during a power transition.

Co-generation Plants: Ensuring a seamless connection between onsite turbine generators and the public utility grid.

Marine Power Systems: Synchronizing multiple shipboard diesel generators to share the electrical load without interruption.

Mobile Power Modules: Used in rental power units where fast, reliable synchronization is required for varying grid conditions.

8440-1706 A SPM-D11

Product Advantages and Features

Full Three-Phase Sensing: Unlike single-phase units, the SPM-D11 monitors all three phases of both the generator and the bus, providing superior safety and accuracy.

Integrated Check-Sync: Includes an internal “Slip Window” and “Dwell Time” logic to ensure the breaker only closes when the electrical conditions are perfect, preventing mechanical damage to the generator.

Analog & Discrete Bias: Capable of sending ±10V or 4-20mA signals to speed governors and voltage regulators (AVRs) to force the generator into alignment.3

Microprocessor Precision: Digitally calculates the exact moment to send the “Close” signal to the breaker, accounting for the inherent mechanical delay of the circuit breaker itself.

User-Friendly HMI: The front-facing LCD and push-buttons allow for easy commissioning without the absolute need for a laptop in the field.

8440-1706 A SPM-D11

Other Models in the Same Series

The SPM-D (Synchronizer Power Manager – Digital) family includes:

SPM-D10: Standard synchronizer (basic version).4

SPM-D11/LSX: Synchronizer with added load-sharing and export control capabilities.5

SPM-D21: A more advanced version designed for two-breaker control (e.g., generator breaker and tie breaker).6

8440-1431: A specific variant of the SPM-D11 series with custom firmware for specialized utility requirements.

Introduction

The Woodward 8440-1706 (SPM-D11) is a robust, microprocessor-based synchronizer that eliminates the human error associated with manual generator paralleling.

7 By continuously monitoring the voltage and frequency of both the generator and the utility bus, it issues corrective commands to the engine’s governor and voltage regulator.

Once the generator is perfectly “in phase,” the SPM-D11 triggers the circuit breaker, ensuring a smooth transition of power.

It is highly valued for its reliability in critical infrastructure where even a minor synchronization error could result in significant equipment damage.

Woodward 5466-425 Fuel Metering Valve (FMV) Actuator
Parameter Name
Parameter Value
Product Model
Woodward 5466-425
Manufacturer
Woodward
Product Type
Fuel Metering Valve (FMV) / Actuator
Actuator Type
Electro-Hydraulic Servo Valve (EHSV) or Direct Drive Motor (DDV)
Input Signal
Typically ±10 VDC or 4-20 mA from the turbine controller
Position Feedback
LVDT (Linear Variable Differential Transformer) or RVDT (Rotary Variable Differential Transformer) for closed-loop control
Pressure Rating
Designed for high fuel inlet pressures (e.g., 500-1500 psig, specific to application)
Flow Capacity
Sized for the specific turbine’s fuel flow requirements
Linearity & Hysteresis
High precision (e.g., <0.5% full scale)
Response Time
Fast, capable of responding to rapid load demands
Materials
Stainless steel, high-strength alloys compatible with fuel (natural gas, diesel)
Operating Temperature
-40°C to +120°C (or higher, depending on installation)
Connections
SAE or NPT ports for fuel inlet and outlet; electrical connector

Technical Specifications

Parameter Name	Parameter Value
Product Model	Woodward 5466-425
Manufacturer	Woodward
Product Type	Fuel Metering Valve (FMV) / Actuator
Actuator Type	Electro-Hydraulic Servo Valve (EHSV) or Direct Drive Motor (DDV)
Input Signal	Typically ±10 VDC or 4-20 mA from the turbine controller
Position Feedback	LVDT (Linear Variable Differential Transformer) or RVDT (Rotary Variable Differential Transformer) for closed-loop control
Pressure Rating	Designed for high fuel inlet pressures (e.g., 500-1500 psig, specific to application)
Flow Capacity	Sized for the specific turbine’s fuel flow requirements
Linearity & Hysteresis	High precision (e.g., <0.5% full scale)
Response Time	Fast, capable of responding to rapid load demands
Materials	Stainless steel, high-strength alloys compatible with fuel (natural gas, diesel)
Operating Temperature	-40°C to +120°C (or higher, depending on installation)
Connections	SAE or NPT ports for fuel inlet and outlet; electrical connector

The Woodward 5466-425​ delivers critical performance through its closed-loop servo control system.

The core of its operation involves comparing the valve’s actual position (measured by the integrated LVDT/RVDT) to the desired position commanded by the turbine controller.

Any difference (error) between these two signals is amplified and used to drive the actuator—either by porting hydraulic fluid to a piston (in an electro-hydraulic design) or by turning a motor (in a direct drive design).

This continuous correction ensures the valve spool or poppet is positioned with extreme accuracy, resulting in precise fuel flow metering

5466-318

MicroNet Digital Controller 5466-318 is a Triple Modular Redundant Kernel Power Supply module.

This module MUST be used/matched with the TMR040 CPU module.

The 5466-318 unit can regulate the incoming power supply to 5 VDC or 10 A for the remaining kernel sections.

5466-318 Technical Specifications

Output Current    max. 10 A

Standards    CE (EMC) and CSA

Power Consumption    24 VDC

Output Voltage    5 VDC ±5%

Chassis    MicroNet TMR

Input Voltage    24 VDC ±10%

Features    One LED for Power Supply Health

CPU    TMR040

About the 5466-318

Designed by Woodward Inc for the MicroNet Digital Control Series, the 5466-318 module was designed as a Triple Modular Redundant (TMR) Kernel Power Supply (P.S) module.

When this module is installed it will be used in applications that operate on a MicroNet TMR system as one of three kernel power supplies.

When installed this module will be inserted into the first slot of the kernel section.

Please note that prior to removing a module such as this, all modules within the MicroNet TMR Kernel Power supply must be removed.

The physical makeup of the 5466-318 module is metal and only has one LED on the front faceplate of the module.

The LED on the faceplate of the module is used to indicate the Power Health supply of the device.

This module will operate on a power supply of twenty-four volts of direct current which comes from the MicroNet main power source.

After the power supply has been received from the main MicroNet power source it will regulate it to either 10 A or 5 VDC for the remainder of the kernel section.

Woodward 5453-277 TMR Power Supply Chassis

Brand/Manufacturer: Woodward

Order Number: 5453-277

Description

The Woodward 5453-277 is a Triple Modular Redundant (TMR) Power Supply Chassis designed specifically for MicroNet TMR systems.

It provides reliable and fault-tolerant power distribution to critical system modules, ensuring continuous operation in high-availability control environments.

With its redundant architecture and load-sharing capability, the chassis helps maintain system stability and prevents failures caused by power supply interruptions.

Specifications

Part Number: 5453-277

Manufacturer: Woodward

Product Type: TMR Power Supply Chassis

Key Features

Redundant Power Design

Supports multiple redundant power supply modules to ensure uninterrupted operation in the event of a power supply failure.

Load-Sharing Capability

Evenly distributes electrical load across power supply modules, improving efficiency and preventing overload conditions.

Seamless Power Distribution

Delivers stable, uninterrupted power to essential system modules, maintaining critical operations during power fluctuations or failures.

Flexible Configuration

Allows configuration of different power supply options to meet varying voltage and system requirements.

MicroNet TMR System Compatibility

Specifically engineered for seamless integration with MicroNet TMR systems, supporting mission-critical control functions in demanding industrial applications such as power generation and turbine control.

Support for Multiple Module Versions

Compatible with various power supply module versions, providing adaptability and future-proofing for evolving system needs.

The Woodward 5453-203 is a specialized 2-Line Display Operator Interface Panel designed for use within the MicroNet and NetCon digital control platforms.

1 It serves as a compact Human-Machine Interface (HMI), providing operators with real-time system data, alphanumeric feedback, and manual control capabilities for gas and steam turbine control systems.2

Technical Parameter Table

Parameter	Specification
Model Number	5453-203
Product Type	MicroNet 2-Line Display Operator Interface
Display Type	Alphanumeric VFD (Vacuum Fluorescent Display)
Input Voltage	12 VDC (Nominal)
Current Draw	650 mA @ 12 VDC
Communication Ports	RS-232, RS-422
Connector Type	DB9 (Standard Serial)
Operating Temp	-40°C to +70°C (-40°F to +158°F)
Dimensions	305mm (H) x 356mm (W) x 152mm (D)
Weight	Approximately 1.82 kg (4.0 lbs)

Related Models

The 5453-203 typically functions alongside these MicroNet series components:

5466-1035: MicroNet TMR (Triple Modular Redundant) CPU Module.

5466-318: MicroNet TMR Kernel Power Supply Module.3

5466-316: Analog Combo Module (I/O).4

5464-823: Master CPU Module (used in older NetCon architectures).

5453-203

Application Cases

Gas Turbine Control: Used as the primary on-skid interface for monitoring turbine RPM, exhaust temperatures, and fuel valve positions.

Steam Turbine Regulation: Facilitates operator interaction for start-up sequences and manual speed overrides.

Compressor Stations: Monitoring surge parameters and discharge pressures in oil and gas pipeline applications.

Power Plant Automation: Serving as a local diagnostic tool for MicroNet TMR systems in large-scale utility grids.

5453-203

Product Advantages and Features

Ruggedized for Industrial Environments: Wide operating temperature range allows for installation in harsh turbine environments where standard screens would fail.

Triple Modular Redundancy (TMR) Support: Engineered to interface seamlessly with Woodward’s high-availability 2-out-of-3 voting architectures.

Clear Alphanumeric Feedback: The high-contrast display ensures that critical fault codes and system status messages are readable even in low-light conditions.

Compact Footprint: Ideal for panel mounting in tight spaces or on-engine control cabinets.

Longevity: Although categorized as a legacy component, it is widely supported in “Lifecycle” service programs for aging infrastructure.

Other Models in the Same Series

5453-276: Relay Discrete Input Module.5

5453-278: MicroNet 12-Slot Chassis.6

5453-759: MicroNet Plus 14-Slot Chassis.7

5453-204: Extended Display/Keypad variant (often found in similar architectures).

Important Support Note

The 5453-203 was part of a series (including 040/060 CPUs) that was formally moved to “Obsolescence” by

9907-1106 CPC-II current-pressure converter

The Woodward CPC-II is a current pressure converter used to control steam intake valves or associated servo systems.

CPC-II connects

Receive 4-20mA current setting input to provide an accurate and stable pressure output proportional to the input current.

In addition to precision

For pressure control, CPC-II also features ease of installation and maintenance. With sufficient support, the CPC-II face can

With a variety of brackets. The wiring enters the CPC-II through a protective connector or tube.

Open the top cover to connect. Dynamic parameter adjustment via computer

On the tool software.

The housing is made of anodized aluminum to seal and protect the CPC with 4 bolts on the end face.

Aluminum cap with thread

Provides protection, two level lock bolt to ensure that the upper cover is properly assembled.

The protection rating is IP56 (according to IEC 60529), and there is under the base

A spiral return spring, which is attached to the lower part of the control shaft.

The return spring brings the internal valve to the fully open by-pass position when power is lost.

he Woodward CPC-II is a current pressure converter used to control steam intake valves or associated servo systems.

CPC-II connects

9907-1106

Receive 4-20mA current setting input to provide an accurate and stable pressure output proportional to the input current.

In addition to precision

For pressure control, CPC-II also features ease of installation and maintenance.

With sufficient support, the CPC-II face can

With a variety of brackets. The wiring enters the CPC-II through a protective connector or tube. Open the top cover to connect. Dynamic parameter adjustment via computer

On the tool software.

The housing is made of anodized aluminum to seal and protect the CPC with 4 bolts on the end face.

Aluminum cap with thread

Provides protection, two level lock bolt to ensure that the upper cover is properly assembled.

The protection rating is IP56 (according to IEC 60529), and there is under the base

A spiral return spring, which is attached to the lower part of the control shaft.

The return spring brings the internal valve to the fully open by-pass position when power is lost.

Rotary control valve

9907-1106

A new three-way valve controls the output or drainage of the oil supply (see Figure 1-2).

The valve consists of a stainless steel bushing and rotates within it

Composed of stainless steel shafts, this design ensures accurate, reliable and non-contaminated operation of the turbine with standard oil.

actuator

The CPC uses a fixed Angle rotary torque actuator, the permanent magnet rotor is directly connected to the hydraulic valve, and the rotor position is integrated in

Circuit measurement on PCB board.

Through the adjustment of the microprocessor, the H-driver implements precise control of the actuator and maintains the pressure

The force is consistent with the set value.

Printed circuit board

The circuit board is mounted on the top of the housing (see Figure 1-3). The circuit board has the following functions:

• Power supply

• Isolation of input and output circuits

• A second redundant setting or pressure feedback value input

• Pressure control

• Actuator position control module

• Type H drive

WOODWARD 5233-2089  Control Unit

Display parameters:

True color 65536K TFT-LCD display; 640 x (3H) x 480 (V) pixels;

Effective display area 170.90 (H) x 182.2 (V) (8.4 inch diameter)

450cd/㎡ CCFL backlight (replaceable CCFL, 25 ° C 24 hour use, can maintain at least 50000 hours)

Chinese: (GB2312-80 codes) Simplified Chinese characters/English font support

Support for Windows fonts

5233-2089

4-wire resistive touch panel

Storage: 4MB NOR FLASH/32M NAND FLASH

Memory: 32M SDRAM

ontrol Module Specifications:

Input voltage: 24 VDC

Output voltage range: 0-10 VDC

Current capacity: 5 A

Operating temperature range: -40°C to 85°C

Dimensions: 4.5″ x 3″ x 1.2″

Weight: 0.3 lbs

5233-2089

Applications:

Industrial automation

Power generation

Process control

The WOODWARD 5233-2089 Control Module is a versatile and reliable device used for various control applications.

With its wide input and output voltage range, it can be integrated into different systems seamlessly.

It is designed to operate in harsh environments with its wide temperature range and robust construction.

The compact size and lightweight design make it easy to install and integrate into existing systems.

Whether it is for industrial automation, power generation, or process control, the WOODWARD 5233-2089 Control Module delivers accurate and precise control.
