1. Product overview
   Bently Nevada 330130-045-00-00 is a special extension cable for 3300x8mm proximity sensor system, which is used to connect 3300x8mm probe and Proximitor sensor to ensure high-precision vibration and position measurement signal transmission. The cable adopts optimized electrical and mechanical design and is suitable for industrial machinery condition monitoring applications, such as turbines, compressors, pumps and motors.
2. Main technical features
   (1) High performance electrical characteristics
   Low-resistance design: the typical value of the center conductor resistance (RCORE) is 0.88 Ω 0.13 Ω (4m in length), ensuring low-loss signal transmission.
   Shielding and anti-interference: 75Ω triaxial cable structure and fluorinated ethylene propylene (FEP) insulation layer are adopted to effectively suppress electromagnetic interference (EMI) and radio frequency interference (RFI).
   Compatibility: It is completely matched with 3300 XL 8mm probe and Proximitor sensor, supporting plug and play without additional calibration.
   (2) Strong and durable mechanical structure
   High tensile strength: CableLoc patented design can bear a tensile force of 330N(75lbf) to prevent the cable from accidentally falling off.
   Anti-oil and anti-corrosion: Optional FluidLoc version, to prevent oil from penetrating into the cable, suitable for lubricating oil or coolant environment.
   Gold-plated ClickLoc connector: corrosion-resistant, oxidation-resistant, reliable connection can be ensured only by finger tightening, and it has locking mechanism.
   (3) Environmental adaptability
   Standard temperature range:-52 C to+177 C (-62 F to+350 F), suitable for most industrial environments.
   Extended temperature range (ETR) option: Up to 260 C (500 F), suitable for high temperature applications (such as gas turbine exhaust section).
   Minimum bending radius: 25.4mm(1 inch), easy to install in narrow space.
3. Typical application
   Vibration monitoring of rotating machinery (API 670 standard application)
   Axial and radial position measurement (such as turbine shaft displacement)
   Keyphasor® speed signal acquisition
   Mechanical monitoring in high temperature or oily environment
   Step 4 summarize
   Bently Nevada 330130-045-00-00 3300XL extension cable has become the key component of industrial machinery condition monitoring system because of its low resistance, anti-interference, high mechanical strength and wide temperature adaptability. Its modular design supports rapid replacement, ensures long-term stable operation of the system, and is suitable for harsh working conditions in petroleum, chemical, electric power, shipbuilding and other industries.

1. Module overview
   125840-02 is a Low Voltage AC power input module (PIM) in Bently Nevada 3500 series mechanical protection system, which belongs to the Legacy power solution of this system. This module needs to be used together with the supporting Legacy low-voltage AC power supply module to provide power support for the 3500 rack.

Key characteristics
Traditional system components: It belongs to the early power supply solution of Bently Nevada and is incompatible with the new Universal AC power supply system.
Dedicated voltage input: designed for a specific low-voltage AC input range (refer to the specific specifications, and the parameters of this model are not clearly listed in the document).
Safety protection: built-in overvoltage protection mechanism, abnormal voltage will trigger PIM fuse to open.
Modular architecture: the standard half-height module size (120.7mm×25.4mm×114.3mm) is adopted.

2. Technical parameters (inference)
   Note: The original document did not directly list the parameters of 125840-02, and the following is inferred based on similar Legacy modules.

Possible specifications of parameter categories (refer to Legacy Low Voltage DC analogy)
The input voltage is expected to be in the range of 20-30Vac (official confirmation is required).
The fuse specification may use 01720045 5A/500V fast-melting fuse.
Installation position 3500 Half-height slot on the left side of rack
Environmental adaptive working temperature-30 C to+65 C.

106m1081-01 universal AC power input module (PIM) is one of the core components of Bentley Nevada 3500/15 AC and DC power supply system, which is specially designed for universal AC voltage input. The module is used in conjunction with general AC power supply to provide stable and reliable power input support for 3500 series mechanical protection system.
Key features
Wide voltage input range: support 85–264 VAC RMS (non-hazardous area) and 85–250 VAC RMS (hazardous area), and adapt to different global power grid standards.
High compatibility: it is compatible with the new universal AC power supply, but not with the traditional high/low voltage AC PIM.
Safety protection: Built-in overvoltage protection mechanism, PIM fuse will be disconnected when overvoltage occurs to avoid equipment damage.
Modular design: adopt standard half-height module size, which is convenient for installation and maintenance.

Description
The 3300 XL 8 mm Proximity Transducer System consists of: o One 3300 XL 8 mm probe, o One 3300 XL extension cable1, and o One 3300 XL Proximitor Sensor2.
The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements3.
The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system also fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable4 with other non XL 3300 series 5 mm and 8 mm transducer system components5. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space6,7.
Proximitor Sensor
The 3300 XL Proximitor Sensor incorporates numerous improvements over previous designs. Its physical packaging allows you to use it in high-density DIN-rail installations. You can also mount the sensor in a traditional panel mount configuration, where it shares an identical 4-hole mounting “footprint” with older Proximitor Sensor designs. The mounting base for either option provides electrical isolation and eliminates the need for separate isolator plates. The 3300 XL Proximitor Sensor is highly immune to radio frequency interference, allowing you to install it in fiberglass housings without adverse effects from nearby

Technical analysis of Bently Nevada 125768-01 RIM I/O module

1. Core functions
   Interface configuration: integrated RS-232/RS-422 serial communication port.
   Protocol support: compatible with Modbus RTU/ASCII, specially designed for 3500 monitoring system.
   Signal conversion: realize bidirectional transmission of frame data and external system.

Jumper configuration
Terminal resistance: 120 Ω (enabled for RS-422 long-distance transmission)
Flow control mode: RTS/CTS hardware flow control (jumper J1:1-2)

Security and authentication
Industry standard:
API 670 (mechanical protection system)
IEEE 1156 (serial communication reliability)
Explosion-proof certification: ATEX Zone 2 (optional model)
Operational suggestion
Configuration steps:
Use 3500 configuration software to set Modbus register mapping (refer to section 4.5 of the document).
Disable unused protocols to reduce CPU load
EMC protection:
When the transmission distance of RS-422 is more than 15m, twisted-pair shielded cable (AWG22+) is used.

Description
3500 Internal Barriers are intrinsically safe interfaces that provide explosion protection for transducer systems connected directly to the 3500 Machinery Protection System. The internal barriers are fully compatible with the 3500 System and provide a convenient and cost-effective solution for installing all types of transducer systems within a hazardous area.
The internal barriers are fully compatible with the 3500 System and provide a convenient and cost-effective solution for installing all types of transducer systems within a hazardous area
Unlike external barriers, 3500 Internal Barriers are an integral part of the 3500 System and will not degrade the system’s performance.
We offer Bently Nevada transducer systems with comprehensive approvals for hazardous area installations. The transducer systems are matched to those of the 3500 Internal Barriers. See Compatible Monitors and Transducers on page 8.

Each component complies both individually and as part of a system with the safety requirements of North American and international standards.  Hence, you don’t have to reference individual certificates to verify the compatibility between components.
Standard and internal barrier monitors can reside within the same 3500 rack. You can upgrade standard monitors  by replacing existing I/O modules with those that contain internal barriers
Installation Guidelines
The internal barriers for a 3500 rack are incorporated in special Monitor I/O Modules.   These barriers provide explosion protection for transducer systems that are connected to the 3500 system.  An intrinsically safe (IS) earthing module provides the IS earth connection through the 3500 system backplane. The IS Earth Module requires a dedicated I/O module position and precludes the use of this monitor position for other 3500 System modules.  This limits a standard 19-inch rack to 13 monitor positions.  Furthermore, a number of installation options are not available when internal barriers are installed in a 3500 rack.For users who need to know or purchase such equipment, they can contact the supplier for more information by email itadcs@163.com or WhatsApp message +86 17750019513.

Core characteristics
4-channel independent monitoring
Support radial vibration, thrust position, differential expansion, eccentricity and REBAM (shaft relative vibration) measurement.
Static value parameters (such as peak-peak value, GAP voltage, etc.) can be configured independently for each channel.
High precision signal conditioning
Adapted to Bently Nevada eddy current sensor (such as 3300/7200 series), with input range of -2V to -18V DC.
Dynamic signal processing ensures high resolution measurement (typical accuracy 1% fs).
Flexible alarm configuration
Each channel supports two-level alarm (Alert/Danger), and the threshold is programmable.
Can be associated with static values (such as 1X amplitude and phase) to trigger protection logic.
Modular extended design
Plug and play installed in 3500 rack (compatible with 125388-01 chassis).
Through the rapid configuration of 3500 configuration software, it supports hot plug maintenance.

The 3500/92 Communication Gateway module provides extensive communication capabilities of all rack monitored values and statuses for integration with process control and other automation systems using both Ethernet TCP/IP and serial (RS232/RS422/RS485) communications capabilities.  It also permits Ethernet communications with 3500 Rack Configuration Software and Data Acquisition Software.
Supported protocols include:
l Modicon Modbus protocol (via serial communications)
 l Modbus/TCP protocol (a variant of serial Modbus used for TCP/IP Ethernet communications)
 l Proprietary Bently Nevada protocol (for communication with 3500 Rack Configuration and Data Acquisition Software packages)

The 3500/92 supports the communication interfaces, communication protocols, and other features from the original 3500/90 with the exception of the primary value Modbus registers.  The 3500/92 now has a Configurable Modbus Register Utility, which can provide the same functionality originally addressed by the primary value Modbus registers.
For users who need to know or purchase such equipment, they can contact the supplier for more information by email itadcs@163.com or WhatsApp message +86 17750019513.
3500/62
3500/92 136180-01
3500/05 16
128275-01-E
135489-03
128275-01

​

Bently NevadaMachineryCondition Monitoring
Description
Thermal Case Growth Measurements in Large Turbines

An important position measurement in Turbine Supervisory Instrumentation (TSI) is case expansion. Case expansion (sometimes referred to as shell expansion) is the thermal growth of the machine case as it expands during machine startup and on-line operations.  The case expansion transducer system is typically mounted on the foundation at the opposite end from where the turbine casing is attached to the foundation and provides information about the growth of the machine case relative to the foundation.
Case expansion is a parameter that you should use a dual transducer arrangement to measure.  This arrangement provides information about the position of the sliding feet on the machine case.  A condition that obstructs or jams one foot could distort the case and damage the machine.  The dual case expansion transducer configuration in conjunction with the 3300 or 3500 monitors provides an alarm for this condition.  The high temperature dual case expansion transducer configuration is compatible only with the 3500/45 Position Monitor.
Case expansion measurements also enable you to determine whether machine conditions are exceeding expected temperature growth differentials.  This is primarily a startup parameter that determines whether the machine casing and rotor grow thermally at nearly the same rate.  Different rates of thermal growth can cause the rotating and stationary parts of the machine to rub.
The case expansion transducer assembly consists of a linear variable differential transformer (LVDT), which is housed in a weatherproof, protective enclosure.
How a Case Expansion Transducer Works
The case expansion transducer system uses the LVDT to measure the machine case thermal growth.

A rod on the LVDT connects to the machine.  As the machine case grows, the rod moves inside the LVDT and changes the signal in the LVDT.  The transducer electronically conditions the signal and outputs it to a monitor for display

Bently Nevada’s Electronic Overspeed Detection System for the 3500 Series Machinery Detection System provides a highly reliable, fast response,  redundant tachometer system intended specifically for use as part of an overspeed protection system.   It is designed to meet the requirements of American Petroleum Institute Standards 670 and 612 pertaining to overspeed protection.

3500/53 modules can be combined to form a 2-out-of-2 or 2-out-of-3 (recommended) voting system.

The use of redundant power supplies in a 3500 rack containing the Overspeed Detection System is required.
Specifications
Inputs Signal: Input Impedance: Power Consumption: Transducers: Each Overspeed Detection module accepts a single transducer signal from a proximity probe transducer or magnetic pickup.  The input signal range is +10.0 V to  -24.0 V.  Signals exceeding this range are limited internally by the module. 20 k Ω. 8.0 Watts, typical. Bently Nevada 3300 8 mm Proximitor®; 3300 16 mm HTPS, 7200 5 mm, 8 mm, 11 mm, and 14 mm Proximitor®; 3300 RAM Proximitor®, or Magnetic pickups
